Category: Motor
Bafang G311 Standard Wind (8.4 rpm/V) Front Geared Hub Motor with 9-pin Waterproof Higo Z910 Motor Plug. Meant for 24″, 26″ and 700c Wheels
The Bafang G311 front motor is a compact disk compatible 2.3kg rear hub with a nominal 250-350 watt power rating that works great for stealthy systems that do not require significant assist for steep hills or cargo. This motor includes an internal 6-pole speedeometer sensor so it can use a CA-DP device and not require an exeternal speedo pickup. It has a spiral gears on the initial reduction of a double stage planetary gear and is exceptionally quiet for a geared motor. This hub is wound with a moderate speed winding (8.4 rpm/V) for 26″ and 700c wheels.
Uses 9-pin overmolded Higo Z910 waterproof connector for the motor phase, hall, and speedo wires.
Has internal tabbed washers for anti-torque rotation with the dropouts and a round 10mm axle. Does not work with conventional torque arms.
Rims
- DT Swiss 535D
Spokes
- Eker referensmodell | DT Swiss Champion J-bend 2.0 mm (14G)
Nipples
PRO LOCK – FACTS
- DT Pro Lock nipples prevent the spoke-nipple connection from loosening
- Wheel durability improves up to 20 times compared to non Pro Lock builds
- Suitable for either hand or machine built wheels. Use of grease or oil not recommended
- All DT Swiss nipples are available with and without DT Pro Lock
Referens
- Nippel referens | DT Swiss standard Prolock 2,0 mm brass
